HEAVY DUTY GRADER BLADE HYDRAULIC 8FT

Description

Hayes 8FT Heavy Duty hydraulic grader blade for 50–100 hp tractors. It has hydraulic swing, manual tilt, left/right offset capability, a 2400 mm blade width and Category 2 linkage. SKU 43310.

• Hydraulic swing function
• Manual tilt function
• Can be offset left or right
• Rated for tractors between 50–100 hp
• Reversible and replaceable carbon-hardened steel blade
• 7 mm reinforced moldboard

Hydraulic ram and hoses for the tilt function can be supplied for an extra $800. A wheel kit with manual ratchet adjustment can be supplied for an additional $1,200.

Specifications

Horsepower	50–100 hp
Width	2400 mm
Hydraulic fittings	1/2 inch male
Pin Size	CAT 2
Weight	430 kg

• The product is shipped in a steel frame to enable cost-effective freight, therefore some assembly is required.
• 12 months manufacturing warranty, excluding consumables.
