$5,490 inc gst

SKU: 38030 Capacity: 65-120hp Categories: ,



  • Reliable extra heavy duty gear box
  • Oil bathed, hardened and straight cut drive gears
  • Eight inch slip clutch to protect gearbox and gear drive
  • Heavy gauge and ridged box construction deck
  • Spring and pin adjustable rear trailing door
  • Multiple depth adjustment via the skids
  • 7mm thick, 80mm wide hardened steel tines
  • Six tines per flange
  • Backed by Hayes field knowledge, technical support and stock of consumables and spare parts


* Please note – photo shown is of the Extra Heavy Duty 1800




Horsepower 65-120hp
Cut width 2,000mm
Offset None
Tine length 200mm
Max depth 170mm
Qty tines 54
Flanges 9
Drive Gear
Hitch pins CAT 2
PTO rpm 540
Overall width 2,200mm
Weight 560kg



  • The PTO shaft is included in the price
  • The gear box and side gear drive require oil, to ensure the unit is filled in the correct location/s, to the correct level with the correct oil we suggest having us fill it at a charge of $60 inc gst
  • The product is shipped in a steel frame to enable cost effective freight therefore some assembly is required
  • 12 months manufacturing warranty (Excludes consumables such as tines, etc.) and 24 months gearbox warranty
