TRACTOR SLASHER 4FT MEDIUM DUTY

$1,990 inc gst

SKU: 25015 Capacity: 20-40hp Categories: ,

Description



  • Ideal for smaller tractors where the implement weight is a concern
  • Robust 4mm deck with an additional 6mm of plating under the gear box
  • 40hp gear box tested over many years of service
  • Seven inch slip clutch providing the gear box added protection
  • Step down blades to reduce the risk of the cutter bar hitting objects
  • Reinforcement on the underside of the deck (rather than top) to reduce water pooling and prolonging the deck life
  • Top link chains to rear of slasher allowing the deck to float over undulating terrain
  • Adjustable cut height
  • Front and rear stone guards as well as clutch/PTO cover for safety
  • Backed by Hayes field knowledge, technical support and stock of consumables and spare parts





Specifications



Horsepower 20-40hp
Cut Width 1,150mm
Cut Height 30mm, 65mm, 100mm, 135mm
Offset N/A
Gear box 40hp
Deck thickness 4mm
Hitch pins CAT 1
PTO rpm 540
Overall width 1,300mm
Length 1,560mm
Weight 220kg





  • The PTO shaft is included in the price
  • The gear box requires oil, to ensure the unit is filled in the correct location, to the correct level with the correct oil we suggest having us fill it at a charge of $20 inc gst
  • The product is shipped in a steel frame to enable cost effective freight therefore some assembly is required
  • 12 months manufacturing warranty (Excludes consumables such as blades & belts) and 24 months gearbox warranty
